Corfu

Halius Corfu recessed adjustable LED spot Light with high quality led tecgnology. It provides high lumen output, Eco friendly solution and its compact size makes it easy to install. Rigid Construction.

Make an Enquiry
Categories: , ,

Description

Halius Corfu ceiling recessed LED Down light adjustable, 20W, 1680lm, 12°, 23°, 40° beam angle, 3000K/4000K/6000K CCT options, Die cast aluminum body, White Aluminum reflector, White Finish, IP20, ON-OF driver, 5yrs Warranty.

* Die-cast aluminum construction with a Powder coat finish.
* Adjustable Down Light.
* White Reflector for low glare lighting.
* Compact size and easy installation.
* Suitable for Ceiling Recessed application.
* Smooth Lighting.
* Honeycomb for Glare control option.
* High CRI.

Product Spectfications
Part Number HL-LTG-I-ADL-CORF-020W-3000K-40D-W-ND
Power 20W
CCT 3000K/4000K/6000K
Luminaire Lumen 1680lm
Beam Angle 12°, 23°, 40°
Operating Voltage 58Vdc/350mA
CRI 80+/90+
SDCM <3
Life Span 50000Hrs
Driver Type Constant Current-External
Driver Tridonic
Reflector/Diffuser Aluminum
IP IP20
Color Finish White/Black
Ta(ºC) -30º C to 40º C
Dimension Φ105mm
Body Material Die cast Aluminum
LED Chip Cree COB
Mounting Ceiling Recessed
Cut-out Φ95mm
Warranty 5yrs
Dimming No
Dimming option DALI/0-10V/1-10V/Phase-cut
